Introduction#
Brio is a cloud-hosted AI co-pilot for ROS 2 robots. It pairs a Jetson-side ROS 2 node that snapshots robot state with a FastAPI service that runs a supervisor agent, which dispatches tool calls back to the operator’s machine over SSE. The whole thing lives in a single uv workspace — brio-monolith — that bundles the cloud API, local CLI, ROS 2 node, and shared libraries into one repo. This post walks through how that repository is organized and why each piece exists.
We created a demo for what we’ve done for Brio that you can find here:
The high-level architecture#
There are two runtime components that talk to each other over the network:
brio-fastapiis the cloud service. It accepts the robot state, hands it to a Pydantic-AI supervisor agent (with explorer and coder sub-agents under it), streams the agent’s reply back, and exposes an MCP/SSE bridge so the agent’s tool calls can reach the operator.brio(the local CLI) sits on the operator’s laptop. It opens a streaming connection to the FastAPI service, receives MCP tool calls —bash,read_file,write_file— and executes them locally against the operator’s environment.
Auth, per-user API keys, and usage accounting live in Supabase, with migrations checked into supabase/migrations/.
The workspace layout#
The repo is a uv workspace, declared in the root pyproject.toml. Workspace members are split between apps/ (deployable things) and libs/ (shared code):
| Path | What it is |
|---|---|
apps/brio-fastapi | Cloud API. /v1/debug runs the agent, /v1/cli/* is the MCP SSE bridge, /v1/admin/users* handles user management, /mcp exposes FastMCP. |
apps/brio | Local CLI. POSTs queries, streams MCP tool calls back, executes them. |
libs/aiagent | The Pydantic-AI agents themselves — supervisor, explorer, coder, plus persistence and prompts. |
libs/brio-shared | Shared pydantic models (RobotState and friends) and the MCPClient protocol. |
libs/ingest | Placeholder for future ingestion work. |
supabase/migrations | Users table, api_keys, Stripe columns, auth trigger. |
scripts/ | Manual MCP and endpoint smoke tests. |
Everything is built and managed by uv sync from the root.
Why a monolith?#
The “monolith” framing is deliberate. The two runtime components are tightly coupled by a shared data contract — RobotState, MCP message shapes, the API key format — and a single repo lets all four workspace members evolve that contract together. A change to the RobotState schema lands in libs/brio-shared and immediately breaks both the FastAPI route and the ROS 2 publisher at type-check time, instead of drifting silently across two separate repos.
It also keeps the test surface honest: pytest is configured at the root with asyncio_mode = "auto" and explicitly excludes the knowledge/ submodules from collection, so a single uv run pytest exercises the whole system.
The knowledge submodules#
There’s various submodules that include extensive examples and documentation to enable Brio to be better at robotics-specific applications in comparison to tools like Claude Code or Cursor. We have various documentation and add as much relevant informaiton into a vector database. When we get asked quesitons, we then load that information and ensure that the agent has all the relevant possible information to make informed robotics design decisions.
Takeaways#
The Brio monolith is a clean example of a small-team AI product that spans cloud, edge, and CLI without fragmenting into a dozen repos. A uv workspace handles the Python side, colcon handles the ROS 2 side, a single shared library pins the data contract between them, and Supabase carries the auth and billing state. If you’re building something similar, feel free to reach out at pat@getbrio.org and I’d love to get your take on what we’re building.
